Product Overview

The MOZA AY210 is a dual-motor force feedback yoke base delivering 9 N·m of sustained roll torque and 210N of pitch force across a full 180° rotation. Its aluminum alloy housing, 15-bit magnetic encoder, and 1000Hz USB refresh rate provide precise, responsive control. The all-aluminum quick release enables tool-free yoke swaps between MOZA Yoke Series handles, while the front panel features 13 programmable switches with RGB lighting and telemetry sync. Native telemetry force feedback works in MSFS 2020/2024, X-Plane 12, and DCS World — no plugins required.

Get Started

MOZA Cockpit
All-in-one control software

User Manual
Product features and guides

Accessories
Compatible accessories

Specifications

Specification	Details
	Physical
Dimensions	243 × 403 × 216 mm
Weight	8.0 kg
Housing Material	Aluminum alloy; high-strength steel chassis
	Performance
Motors	Dual high-performance servo motors
Sustained Roll Torque	9 N·m
Max Pitch Force	210N (push/pull)
Travel Distance	150 mm
Roll Rotation	±90° (full 180° range)
	Electronics
Encoder	15-bit magnetic encoder
Processor	280MHz high-speed processor
USB Refresh Rate	1000Hz
Power	216W \| 110–220V AC → 36V DC
	Controls & Connectivity
Front Panel Switches	13 programmable (RGB, telemetry sync, long-press)
Quick Release	All-aluminum, tool-free swap
Connection Ports	Power, USB, throttle, rudder pedals, panel, and more
Emergency Stop Switch	Optional
	Force Feedback
FFB Technology	MCLS proprietary force feedback
Telemetry FFB	Native — no plugins required for MSFS 2020/2024, X-Plane 12, DCS World
	Compatibility
Platform	PC only
Yoke Compatibility	MOZA Yoke Series (MFY and future handles)
Supported Sims	MSFS 2024, MSFS 2020, MSFS X, X-Plane 11/12, DCS World 2.9, War Thunder, Star Citizen, IL-2 Great Battles
Mounting	Direct cockpit mount, aluminum profile; optional desktop clamp ($35 CAD) or suspended clamp
In the Box (Bundle)	AY210 Yoke Base, MFY Yoke, toolkit, user manual, warranty card

Tutorial Video

Flying with the AY210 Yoke Bundle

Unboxing & Setup: AY210 Yoke Bundle

AY210+MFY Tutorial — B737 Touch

Training with AY210 Base & MFY Yoke

AY210 Yoke & MTQ Throttle in MSFS 2024

FAQs

What force feedback does the AY210 provide?

The AY210 delivers 9 N·m of sustained roll torque via dual servo motors and 210N of pitch force (push/pull). It uses MOZA's proprietary MCLS force feedback technology with native telemetry support — no plugins required for MSFS 2020/2024, X-Plane 12, and DCS World 2.9.

What yokes are compatible with the AY210?

The AY210 is compatible with all MOZA Yoke Series handles, including the MFY Yoke. The all-aluminum quick release enables tool-free swaps between handles in seconds. The base is designed exclusively for MOZA Yoke Series products.

How do I mount the AY210?

The AY210 supports direct cockpit mounting and aluminum profile rigs. Optional desktop clamp ($35 CAD) and suspended desktop clamp are available separately. The high-strength steel chassis provides structural rigidity for all mounting configurations.

What flight sims support telemetry force feedback?

Native telemetry FFB is supported in Microsoft Flight Simulator 2020, Microsoft Flight Simulator 2024, and X-Plane 12 — no plugins needed. The AY210 is also compatible with MSFS X, X-Plane 11, DCS World 2.9, War Thunder, Star Citizen, and IL-2 Sturmovik: Great Battles.

What are the front panel switches for?

The 13 programmable front panel switches support RGB lighting, telemetry sync, and long-press commands — all configurable in MOZA Cockpit software. Use them for landing gear, flaps, avionics, autopilot, and other cockpit functions.

Does the AY210 work with Xbox or PlayStation?

No. The AY210 is PC only. It does not support Xbox or PlayStation.
