MOZA FSR2 Formula Steering Wheel Support

Modified on Wed, 10 Jun at 10:28 AM

Get Started

MOZA Pit House
All-in-one control software

MOZA Racing App
Cloud-based mobile control

User Manual
Product features and guides

Accessories
Compatible accessories

Post-Sales Support

Contact Customer Support
support@mozaracing.com

Get Technical Support
Submit New Ticket

Request Repair Service
Contact customer support first

Specifications

Specification	Details
Size	280mm formula-style steering wheel
Back Plate Material	Aerospace-grade aluminum alloy
Face Plate Material	5mm-thick 3K twill carbon fiber
Grip Material	Perforated microfiber leather
Display Screen	4.3-inch touchscreen display
Display UI	Fully customizable
Short-Travel Backlit Buttons	10
Backlit Color Options for Buttons	16.7 million colors
Rotary Encoders	2
Thumb Encoders	3
7-Way Switches	2
Signal Lights	6 LED side-mounted signal lights
Shift Indicator Lights	10 LED top-mounted shift indicator lights
Adjustable Colors for Shift Lights, Signal Lights, and Button Lights	16.7 million colors
Shift Paddles	Hall sensor magnetic carbon fiber paddles
Dual Clutch Paddles	Hall sensor magnetic carbon fiber paddles
Smart Telemetry	Supported
Fully Adjustable RPM LEDs through MOZA Pit House	Supported
Release Method	All-aluminum quick release
Communication Methods	Wireless or via conductive slip ring
Compatibility	It is compatible with all MOZA wheelbases and works with 3rd party wheelbases via MOZA hub.

Tutorial Video

Introducing the FSR2 Formula Wheel

Unlock Your FSR2 for F124

FSR2 Full Feature Breakdown

FSR2 Settings for AC EVO

FSR2 Settings for iRacing

Create Simple DASH for FSR2

Level Up — FSR2 Wheel Review

Reviews

by Sim Racing Pal

by Race Beyond Matter

by The Simpit

FAQs

The force feedback weakens or disappears suddenly.

Restart wheel base , MOZA Pit House and the game.

The shift indicator doesn't match the engine speed.

Follow these steps:
1. Click "Configurate: in the game on the right side on the main page in MOZA Pit House.
2. Turn on the rev speed matching button on the steering wheel setting page.

Insensitive shift paddle / responsive latency / irresponsive / stuck.

Click "Calibrate Paddles" on the Recovery and Reset page in Pit House and calibrate as instructed.

The steering wheel is not successfully paired with the wheel base for a long time.

You can try the following methods:
1. Upgrade the base and steering wheel firmware to the latest version
2. The steering wheel access detection of MOZA Pit House is adjusted to continuous detection
3. Or the steering wheel access detection of MOZA Pit House remains as automatic detection, but a steering wheel automatic detection calibration is performed

How to ensure that the steering wheel can be used normally / the meaning of the change of the steering wheel shift indicator.

1. When the game is not in progress and the MOZA Pit House indicator switch mode has been set to follow the speed, the shift indicator of the steering wheel will continue to breathe purple light under normal circumstances, which means that the steering wheel can be used normally.
2. When the game is not in progress and the MOZA Pit House indicator switch mode has been set to follow the speed, if the steering wheel shift indicator continues to breathe, and the light is blue, it means that the steering wheel is in the upgrade mode at this time, and it needs to be in MOZA Pit House re-upgrades firmware
3. MOZA Pit House cannot check that the steering wheel is connected, and the shift indicator of the steering wheel is periodically moving left and right, which means that the steering wheel is trying to pair with the base. If the steering wheel is unsuccessfully paired with the base for a long time, see "Unsuccessful pairing of the steering wheel with the base for a long time"

The steering wheel centers, but doesn't display as centered in MOZA Pit House.

See Wheel Base FAQs.

The shifter paddle is insensitive.

See "The steering wheel is not successfully paired with the wheel base for a long time", if the problem still cannot be solved, please contact the customer service.
