Specifications

Specification	Details
Dimensions	310mm X 164mm X 175mm
Weight	1950g
Face Plate Material	Carbon fiber
Grip Material	Suede leather
Back Plate Material	Aluminum alloy
Shifter Paddle Material	Aluminum alloy
Rotary Encoder Material	Aluminum alloy
Dash Display	4.3-inch LCD color touch-screen display
Display Resolution	800×480
Shifter Paddles	2
Buttons	8
Thumb Encoders	4
Rotary Encoders	4 (12 positions)
RPM LED Lights	10
Shift Indicator Light Colors	256x256x256 (16.7 million colors)
Release Method	Quick release
Quick Release Material	Aluminum alloy
Communication Method	Wireless or wired
Compatibility	It is compatible with all MOZA wheelbases currently on sale and also works with 3rd party wheelbases via the MOZA hub kit.
Rotary Encoder Mode	Incremental Mode: This mode has two signals – increase and decrease. Discrete Mode: This mode has 12 distinct signals, corresponding to its 12 positions.
Display UI System	Fully customizable with multiple presets

Tutorial Video

From Real Motorsport to Sim Racing

MOZA × Lamborghini Essenza SCV12

Essenza SCV12 SIM Racing Wheel

MOZA × Lamborghini ESSENZA SCV12

FAQs

The force feedback weakens or disappears suddenly.

Restart wheel base , MOZA Pit House and the game.

The shift indicator doesn't match the engine speed.

Follow these steps:
1. Click "Configurate: in the game on the right side on the main page in MOZA Pit House.
2. Turn on the rev speed matching button on the steering wheel setting page.

Insensitive shift paddle / responsive latency / irresponsive / stuck.

Click "Calibrate Paddles" on the Recovery and Reset page in Pit House and calibrate as instructed.

The steering wheel is not successfully paired with the wheel base for a long time.

You can try the following methods:
1. Upgrade the base and steering wheel firmware to the latest version
2. The steering wheel access detection of MOZA Pit House is adjusted to continuous detection
3. Or the steering wheel access detection of MOZA Pit House remains as automatic detection, but a steering wheel automatic detection calibration is performed

How to ensure that the steering wheel can be used normally / the meaning of the change of the steering wheel shift indicator.

1. When the game is not in progress and the MOZA Pit House indicator switch mode has been set to follow the speed, the shift indicator of the steering wheel will continue to breathe purple light under normal circumstances, which means that the steering wheel can be used normally.
2. When the game is not in progress and the MOZA Pit House indicator switch mode has been set to follow the speed, if the steering wheel shift indicator continues to breathe, and the light is blue, it means that the steering wheel is in the upgrade mode at this time, and it needs to be in MOZA Pit House re-upgrades firmware
3. MOZA Pit House cannot check that the steering wheel is connected, and the shift indicator of the steering wheel is periodically moving left and right, which means that the steering wheel is trying to pair with the base. If the steering wheel is unsuccessfully paired with the base for a long time, see "Unsuccessful pairing of the steering wheel with the base for a long time"

The steering wheel centers, but doesn't display as centered in MOZA Pit House.

See Wheel Base FAQs.

The shifter paddle is insensitive.

See "The steering wheel is not successfully paired with the wheel base for a long time", if the problem still cannot be solved, please contact the customer service.
